Name: 2F Straight End Mill - HAO CARBIDE
Price: 99.00 USD
Availability: InStock

Description

Processing Characteristics

High Rigidity and Precision: Features uniform axial force distribution and strong resistance to deformation, making it ideal for high-precision machining tasks involving keyways, shoulders, and similar features.
Smooth, Efficient Cutting: Optimized rake angle geometry results in low cutting forces and extended tool life.
Effective Chip Evacuation: Straight flutes facilitate efficient chip removal, while specialized tooth designs (such as those found on PCB “corn-cob” cutters) effectively prevent clogging and minimize burring.
Structural Versatility: Available in configurations ranging from single-flute to multi-flute designs; material options include High-Speed Steel (HSS) and Carbide, with compatibility for various surface coatings.
Applicable Materials: Suitable for a wide range of materials—including hardened steel, cast iron, copper, PCBs, and wood (for rough cutting)—and is particularly well-suited for finishing operations where high rigidity is a critical requirement.


2F STRAIGHT END MILL
Applicable: 2D engraving, cutting, MDF, hardwood. Features: The tungsten steel cutter body is specifically for CNC engraving machine processing MDF material, combined with hard cutter body and advanced blade. Durable and strong.
SHK	CED	CEL	OVL
3.175	3.175	8	38
3.175	3.175	12	38
3.175	3.175	15	38
3.175	3.175	17	38
3.175	3.175	22	45
3.175	3.175	25	50
3.175	3.175	28	50
3.175	3.175	32	55
3.175	1	3	38
3.175	1.5	7	38
3.175	2	8	38
3.175	2	12	38
3.175	2	17	38
3.175	2.5	12	38
3.175	2.5	15	38
3.175	2.5	17	38
4	4	12	45
4	4	17	45
4	4	22	45
4	4	25	50
4	4	28	50
4	4	32	55
4	4	42	65
6	6	17	50
6	6	22	50
6	6	25	50
6	6	28	60
6	6	32	60
6	6	42	70
6	6	52	80
6	6	62	100
8	8	25	60
8	8	32	60
8	8	42	75
8	8	52	90
8	8	62	100
10	10	32	75
10	10	42	80
10	10	52	100
10	10	62	110
NON-STANDARD SIZE CAN BE CUSTOMIZED
